电动轮椅Electric wheelchair

产品名称:电动轮椅

产品型号:Electric wheelchair

1 "Container loading
quantity" "142/318/375pcs
20GP/40GP/40HQ"
2 Motor 24v/250W*2 Brush
3 Battery 24V 13AH/24V 26AH lithium(2 batteries , one for replace)
4 Charger AC100-240V 50/60HZ Output:24V 2A
5 Controller Joystick
6 Loading capacity 120kgs
7 Charging time 4-6h
8 Forward speed 0-6Km/h
9 Reverse speed 0-6Km/h
10 Turning radius 600mm
11 Climbing ability 12°
12 Driving distance /full charge 15-20km/30-40km
13 Seat and function L400*W430mm*T60mm foldable
14 Backrest L400*H4000*T15mm
15 Front wheel size (inch) 8" PU solid
16 Rear wheel size (inch) Wheelbase 560mm 12" PU Rubber pneumatic
17 Anti-tip wheel size (inch) 50mm×25mm/2×1” PU
18 Controller's current ≤40A
19 Size (unfolded) 1100x630x960mm
20 Size (folded) 610x320x780mm
21 Packing size 650X380X790mm
22 G.W. 38kgs
23 N.W.(With battery) 31kgs
24 N.W.(No battery) 26kgs
